AH 200 A

SPECIFICATIONS

AMPLIFIER
Power
 Continuous: 200 W
Peak: 400 W
Input impedance
 30 kohms (balanced)
15 kohms (unbalanced)
Input sensitivity
 0 dB (0,775 V)
Distorsion (THD + N)
 Max 0.1 %

LOUDSPEAKER
Sensitivity (SPL 1W/1m)
 93 dB
MAX SPL dB 118 117
 116 dB
Frequency response

 40 Hz - 15.000 Hz (± 3db)
30 Hz e 18.000 Hz (- 10db)
Crossover frequency

 1000 Hz / 12 dB/octave
Components
 Low: 2 x 10" woofer long throw
High: 1" driver horn loaded
Construction
 Anti-scratch brown finish
Dimensions (W x H x D)
 368 x 882 x 395 mm / 14.5" x 34.7" x 15.6"
Weight
 34,4 kg / 75,8 lbs
Accessories
 Speaker supporting bracket
